Indoor HFC 227ea FM 200 Gas Suppression System With Maximum System Protection

1 set
MOQ
Negotiation
Price
Indoor HFC 227ea FM 200 Gas Suppression System With Maximum System Protection
Features Gallery Product Description Request A Quote
Features
Specifications
Application: A,B,C
Max Working Pressure: 8.0Mpa
Spraying Time: ≤10s
Relative Humidity: ≤97%
Installation: Indoor
Storage Pressure: 4.2Mpa / 5.6Mpa
Working Power: DC 24V 1.5A
Cylinder Color: Red
Material: Automatic FM200 Fire Suppression System
Actuation: Automatic Or Manual
Highlight:

Indoor FM 200 Gas Suppression System

,

HFC 227ea FM 200 Gas Suppression System

Basic Infomation
Place of Origin: Guangzhou City, Guangdong Province, China
Brand Name: Rongxiao
Certification: CAL,CMA,CNAS,,CCC
Model Number: 70L,90L,100L,120L,150L,180L
Payment & Shipping Terms
Packaging Details: Plywood outer box with bubble bag or paper
Delivery Time: 10 days, subject to quantity negotiation
Payment Terms: L/C, D/P, Western Union, T/T, Credit card
Supply Ability: 18000 sets per week
Product Description

FM200 Gas Suppression System Ensuring Safety with Maximum System Protection





Product Description

The HFC-227ea fire extinguishing system has high fire extinguishing efficiency and requires a smaller gas cylinder room area than the IG541 system. It is suitable for projects with relatively concentrated protection areas and suitable gas cylinder rooms, such as basement substations and transmission and substations. The protection areas usually protected include computer rooms, communication rooms, generator rooms, substations, libraries, archives, museums, etc.





Parameters

NO. Specifications 4.2Mpa sysiem 5.6Mpa sysiem
  •
Capacity 70Ltr,90Ltr,120Ltr.150Ltr,180Ltr 70Ltr,90Ltr,100Ltr,120Ltr.150Ltr,180Ltr
  •
Device model QMP70/4.2,QMP90/4.2.QMP120/4.2,QMP150/4.2,QMP180/4.2 QMP70/5.6,QMP100/5.6.QMP120/5.6,QMP150/5.6,QMP180/5.6
  •
Filling pressure 4.2Mpa 5.6Mpa
  •
Discharge time s10s



Basic parameters

Specifications Volume(L) Nominal diameter of container valve(mm)

Bottle group height

H(mm)

Bottle group outer diameter

D(mm)

QMP70/4.2 70 DN32 1280 Φ325
QMP90/4.2 90 DN32 1515 Φ325
QMP120/4.2 120 DN40 1345 Φ415
QMP150/4.2 150 DN40 1390 Φ465
QMP180/4.2 180 DN50 1380 Φ520
Maximum working pressure (50℃): 5.3MPa; filling pressure (20℃): 4.2MPa; maximum filling density ≤950Kg/mm³




Specifications Volume(L) Nominal diameter of container valve(mm)

Bottle group height

H(mm)

Bottle group outer diameter

D(mm)

QMP70/5.6 70 DN32 1257 Φ370
QMP90/5.6 90 DN32 1494 Φ370
QMP100/5.6 100 DN32 1494 Φ370
QMP120/5.6 120 DN32 1337 Φ370
QMP150/5.6 150 DN40 1375 Φ470
QMP180/5.6 180 DN40 1401 Φ470
Maximum working pressure (50℃): 8MPa; filling pressure (20℃): 5.6MPa; maximum filling density ≤1080Kg/m³






Company introduction:

Guangzhou Rongan Fire Protection Equipment Co., Ltd. is a professional manufacturer of fire protection facilities integrating R&D, production, design and sales services. The company has experts from the national fire protection industry standards committee and a group of professional technical service teams with more than ten years of experience in the fire protection industry, and will spare no effort to provide you with the most intimate and professional comprehensive technical solutions for fire protection engineering products. "Rongxiao" series products produced by the company have passed the national compulsory product certification and the national fixed fire extinguishing system inspection center, with reliable quality and stable performance, and the factory has passed the ISO9001 quality system certification.



Frequently asked questions:

Q1: Are you a manufacturer or a trading company? A1: We are manufacturers.

Q2: How long is the delivery time? A2:10 days, which can be negotiated according to the quantity.

Q3: How to deal with the fault? A3: During the warranty period, we will provide you with a remote emergency plan during working hours. During the free maintenance period, the company will replace spare parts or complete machines that have failed due to defects or quality problems free of charge.
