Fm200 Archives Non-Pollution Automatic Fire Extinguishing System
Product definition:
When the system is activated, the extinguishing agent of the extinguishing agent bottle group is pressurized and transported by the specially designed pressurized gas bottle group according to the design pressure.
Product features:
lThe pressurized ammonia and heptafluoropropane fire extinguishing agent are stored separately.
lThe fire extinguishing agent can be transported over a long distance, up to 230 meters.
lHeptafluoropropane is a colorless, odorless, non-conductive gas fire extinguishing agent that can be liquefied and stored at low pressure at room temperature. (Also known as FM200)
lThe fire extinguishing mechanism has both physical and chemical effects.
lHigh fire extinguishing efficiency.
lIt has the advantages of no pollution to the protected object and no damage to the atmospheric ozone layer.
Bottle group specifications and storage pressure
| Bottle group name | Model specification (l) | Storage pressure (20℃) | ||||
| Nitrogen start-up bottle group | 8 | 6Mpa | ||||
| Nitrogen automatic bottle group | 70 | 13.5Mpa | ||||
| Fire extinguishing agent bottle group | 70 | 90 | 120 | 150 | 180 | 0.3Mpa |
Coefficient of technical performance parameters
| Injection time s | Delay time s | Nozzle inlet pressure Mpa | Starting power supply (DC power supply) | |
| ≤10 | 0~30 | ≥0.7 | ≥0.8 | 24V,1.5A |
Company introduction:
Guangzhou Rongan Fire Protection Equipment Co., Ltd. is a professional manufacturer of fire protection facilities integrating R&D, production, design and sales services. The company has experts from the national fire protection industry standards committee and a group of professional technical service teams with more than ten years of experience in the fire protection industry, and will spare no effort to provide you with the most intimate and professional comprehensive technical solutions for fire protection engineering products. "Rongxiao" series products produced by the company have passed the national compulsory product certification and the national fixed fire extinguishing system inspection center, with reliable quality and stable performance, and the factory has passed the ISO9001 quality system certification.
Frequently asked questions:
Q1: Are you a manufacturer or a trading company? A1: We are manufacturers.
Q2: How long is the delivery time? A2:10 days, which can be negotiated according to the quantity.
Q3: How to deal with the fault? A3: During the warranty period, we will provide you with a remote emergency plan during working hours. During the free maintenance period, the company will replace spare parts or complete machines that have failed due to defects or quality problems free of charge.
