Relationship between density and stability:
Under normal circumstances, oxygen accounts for 21% of the air, nitrogen accounts for 78%, and the rest accounts for 1%. After the IG100 fire extinguishing system is released, nitrogen accounts for about 86.5%.
The IG100 nitrogen fire extinguishing system has obvious stability and is safe and reliable because nitrogen is the main component of the air and is colorless, odorless, non-toxic, non-corrosive, non-conductive, and has no residue after spraying.
System outline installation dimensions
Figure 3 System Outline Diagram
| Specifications | L1 | L2 | L3 | L4 | H1 | H2 |
| QMD15/70 | 340 | 630+340n | 570+340n | 305 | 1050 | 1850 |
|
QMD15/80 QMD20/80 QMD20/82 |
340 | 630+340n | 570+340n | 305 | 1300 | 2030 |
| QMD15/90 | 340 | 630+340n | 570+340n | 305 | 1500 | 2100 |
| QMD20/90 | 340 | 630+340n | 570+340n | 305 | 1500 | 2180 |
Overall dimensions and performance parameters of fire extinguishing agent bottle group
| Specifications | volume(L) | Filling Weight (kg) | Total weight(kg) | gross(mm) | outside diameter(mm) | Outlet connection thread | Filling pressure at 20℃(MPa) |
| DMP70/15 | 70 | 12.47 | 103 | 1600 | 279 | M30×1.5 | 15 |
| DMP80/15 | 80 | 14.25 | 115 | 1800 | 279 | ||
| DMP90/15 | 90 | 16.04 | 120 | 1975 | 279 |
| Specifications | volume(L) | Filling Weight (kg) | Total weight(kg) | gross(mm) | outside diameter(mm) | Outlet connection thread | Filling pressure at 20℃(MPa) |
| DMP80/20 | 80 | 17.48 | 143 | 1830 | 279 | M30×1.5 | 20 |
| DMP82/20 | 82 | 17.92 | 146 | 1860 | 279 | ||
| DMP90/20 | 90 | 19.67 | 157 | 2000 | 279 |
Company introduction:
Guangzhou Rongan Fire Protection Equipment Co., Ltd. is a professional manufacturer of fire protection facilities integrating R&D, production, design and sales services. The company has experts from the national fire protection industry standards committee and a group of professional technical service teams with more than ten years of experience in the fire protection industry, and will spare no effort to provide you with the most intimate and professional comprehensive technical solutions for fire protection engineering products. "Rongxiao" series products produced by the company have passed the national compulsory product certification and the national fixed fire extinguishing system inspection center, with reliable quality and stable performance, and the factory has passed the ISO9001 quality system certification.
Frequently asked questions:
Q1: Are you a manufacturer or a trading company? A1: We are manufacturers.
Q2: How long is the delivery time? A2:10 days, which can be negotiated according to the quantity.
Q3: How to deal with the fault? A3: During the warranty period, we will provide you with a remote emergency plan during working hours. During the free maintenance period, the company will replace spare parts or complete machines that have failed due to defects or quality problems free of charge.
